| Rated Capacities | 50, 75, 100, 200, 300 KG |
| Rated Output | 2.0 mV/V±5% |
| Non-linearity | 0.02 %F.S |
| Hysteresis | 0.02 %F.S |
| Repeatability | 0.02 %F.S |
| Creep (20min) | 0.02 %F.S |
| Temperature Effect On Output | 0.002 %F.S/°C |
| Temperature Effect On Zero | 0.003 %F.S/°C |
| Zero Balance | ±0.0200 mV/V |
| Input Impedance | 380±15 Ω |
| Output Impedance | 350±5 Ω |
| Insulation Impedance | ≥5000 MΩ |
| Safe Overload | 150 %F.S |
| Ultimate Overload | 200 %F.S |
| Operating Temperature Range | -20~60 °C |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| Construction | Aluminum Alloy |
| Protection Class | IP67/ IP68 |
| Cable | Φ5×1,5 m |
| Mode of Connection | Red (EXC+) ,Black (EXC-) ,Green (SIG+) ,White (SIG-) |
